Thermal Swipe

Fingerprint sensor for high quality images

Biometric Hardware > Fingerprint Sensor

Swipe Sensing

The swipe technology is the most used in fingerprint sensor products. The ease of integration into systems makes it a preferred choice for devices.

Robustness

Thanks to the capture method the id3 Thermal Swipe sensor has a self-cleaning function. Coupled with an adapted mechanics it achieves best results in difficult conditions.
Fingerprint sensors
g

Thermal sensor

Thermal technology is based on a different thermal radiation. Pyroelectric materials generate current according to various temperatures.

Cost effective

With very low production costs and a controlled manufacturing process, we can offer a very cost-effective product for fingerprint capture applications.

Applications

PC Access

Building Access

Electronic Keys

Mobile POS

Specifications

  • Manufacturer: id3 technologies,
  • Sensor name: Thermal swipe sensor,
  • Technology: Thermal,
  • Capture method: Swipe,
  • Sensing area: 14*0.4mm,
  • Image size: 300*428 pixels,
  • Pixel depth: 256 grey levels,
  • Image resolution: 500 dpi.

id3 Thermal Swipe associates swipe sensing method with thermal technology for capturing high quality image. With a compact form factor and a low consumption, this sensor is recommended for embedded devices. After capturing several images, id3 proprietary algorithms can reconstruct a full fingerprint image. The device delivers a programmable number of images per second, while an integrated analog-to-digital converter delivers a digital signal adapted to interfaces.
